How To Download Commis ECM Calibrations Using QuickServe Online (QSOL)

 How To Download Commis ECM Calibrations Using QuickServe Online (QSOL)



Please note that not all subscription types will have access to calibration downloads.

 Cummins Workshop Service Repair Manuals+Diagram PDF Dowload

 Changes have been made to the Calibration Download interface to include Aftertreatment
Doser calibrations, Next Generation Cense calibrations, and Dual Fuel calibrations. These
changes can only be seen in the new QSOL3 interface. To verify that you are in the correct
QSOL3 interface, please follow the steps below:
1. If you have QSOL saved as a favorite or bookmark using the outdated URL, you will
need to delete your bookmark
2. Enter the address https://quickserve.cummins.com
3. Once you log in you should see following web address
https://quickserve.cummins.com/qs3/portal/index.html.
The qs3 will let you know that you are in the right version of QSOL.
Instructions to Download:
NOTE: It is recommended to delete or rename any intelect folder and all subfolders from the
C:\Intelect\INSITE\CalibrationWorkspace directory (Figure 1).



2. Click on the Service tab (Figure 3).



3. Click on the Related Information tab (Figure 4).




4. Click on the Calibration Downloads link (Figure 5)


5. When the Calibration download screen pops up, the user has the option to select
Engine Calibration, Doser Calibration, NextGen Cense Calibration, or Dual Fuel
Calibration in the Calibration Type pull-down menu (Figure 6).
6. Select the correct calibration type.


Cummins INSITE 8.7 Pro 2021 Electronic Service Diagnostic Software
7. Enter the appropriate calibration code:
a. For Engine Calibration downloads, enter the Engine Serial Number (ESN) and
ECM Code (without revision number) as shown (Figure 7)


b. For Doser Calibration downloads, enter the Doser calibration code (without
revision number) (Figure 8). The Doser calibration code may also be referred to
as device code.



c. For Next Generation Cense Calibration downloads, enter the Next Gen Cense
calibration code (Figure 9)



d. For Dual Fuel Calibration downloads, enter the Dual Fuel calibration code (Figure
10).



8. Click Download Zip File and the File Download window will open.
9. Click Save (Figure 11) which will save the calibration file to the Downloads folder.
Depending on the computer settings, it may be saved to a different folder.



10. Click on Open folder (Figure 12) which will take you to the zipped calibration file (Figure
13).



11. Right-click on the zipped calibration file. Go to Open with and then Windows
Explorer (Figure 14).


Cummins INLINE 6 Data Link Adapter Truck Diagnostic Tool


12. In the Extract tab, click on Extract all. In the Extract Compressed (Zipped) Folders
window, browse to C:\Intelect\INSITE\CalibrationWorkspace (Figure 15). Click on OK,
and then click on Extract (Figure 16).
Note: Extract Doser calibrations to the C:\ or D:\ root drive.




https://www.heavydutydiag.com/product-tag/cummins/
13. Open INSITE, click on Calibration Selection, click on ECM, and then find the calibration
in the CalibrationWorkspace. If INSITE is already open in the Calibration Selection
window, you will need to click on View  Refresh to refresh the screen (Figure 17).
Note: If the C:\ or D:\ root drive has been selected previously, INSITE will display the
calibration on the selected drive instead.


14. If you do not see the ECM calibration code, go into Tools  Calibration Selection
Certification Codes… (Figure 18) and check that the correct or all certification codes are
in the right hand side window (Figure 19).
