How to Solve the Problem of Doosan Excavator Traveling Motor Not Moving

 Doosan Excavator DH220LC-V walking motor has no action

 2023.07 Doosan DMS-5 Data Monitoring System Diagnostic Software

A  Phenomenon:

 1 There is no movement when walking on the right side, but the 1st and 2nd speeds of walking on

 the    left side are normal;





2  Other actions are normal.



3 The idle pressure for right walking is 38 kg, the pressure during movement is about 60 kg, and the pressure for other movements is normal.











 B  Inspection essentials:

07.2023 HINO DX3 DX III 1.23.7 Download and Install Service



  1. Check the pilot oil pressure;

  2. Check whether the main valve core is stuck;

  3. Whether the rear pump is damaged;

  4. Is there any abnormality in the traveling straight valve core?

  5. Check whether the CTS one-way valve is damaged;

  6. Whether the motor relief valve is damaged;

  7. Check whether there is any damage inside the motor;



  Doosan Diagnostic Tool DDT G2 SCAN( ECU ,DCU)Software 2016

  C  reasons:

   The central shaft spring snap ring inside the walking motor falls off

  D Processing method: Replace the spring circlip and reinstall the traveling motor OK

How to Deal with The Problem of The Whole Machine Shaking When the Doosan Excavator Rotates and The Bucket Arm Works

 How to deal with the problem of the whole machine shaking when the doosanDH220LC-V excavator rotates and the bucket arm works

 Doosan Diagnostic Tool UVIM Support Doosan Excavators High Quality

1. Inspection method:

   A. First analyze whether the cause of the jitter is mechanical jitter or hydraulic jitter. The mechanical

cause is mainly the jitter caused by the internal breakage of the rotary reducer or the oil cylinder. After

checking that the parts are normal and have no damage, mechanical jitter can be ruled out. Normally,

the negative control pressure is measured during rotation and stick action. The pressure during wide-

center action is 6 BAR. The neutral pressure is 40 BAR. Normal.



B·Check that the overflow pressure during rotation is 285 BAR and the bucket arm overflow pressure is 332 BAR.

 2020 Doosan Daewoo Excavator Operation and Repair Manual PDF

  C. According to the analysis, because two actions vibrate at the same time, it can be basically

concluded that the problem lies in the main pump. Damage to the pump's plunger, sliding shoe, etc.

will

cause the actions associated with the pump to vibrate, and some actions do not feel right. obvious.

 2022.11 Doosan DMS-5 3.0.5 Data Monitoring System Diagnostic Software

 2. Reason: After dismantling and inspecting the main pump, a crack in the sliding shoe was found,

       which caused excessive leakage of the plunger and caused working jitter.



 3·Processing method: Clean the main pump and replace the corresponding accessories OK

How to Deal With the Problem That the Rollers on The Doosan Excavator Do Not Rotate and The Parts in Contact With the Tracks Are Abnormally Worn.

 How to deal with the problem that the rollers on the doosan DH55-5 excavator do not rotate and the parts in contact with the tracks are abnormally worn.

 2022.11 Doosan DMS-5 3.0.5 Data Monitoring System Diagnostic Software

  A. Inspection essentials

1.Construction environment Swamps, water conservancy projects, dredging and other construction sites are relatively soft environments.

2.Fault situation a. The upper roller hub does not rotate and the contact position with the crawler track is abnormally worn. b. The failure occurred again within a short period of time after replacing the rollers.

3. Determine the fault During the inspection, it was found that the construction environment of the equipment was soft, and the chassis parts were basically covered by soft soil or attachments, causing the rollers to be unable to rotate normally due to large external forces during operation.

 Doosan Diagnostic Tool UVIM Support Doosan Excavators High Quality





B. Reason: The construction environment is soft, and the chassis parts are basically covered by soft soil or attachments, causing the supporting wheels to be unable to rotate normally due to large external forces during operation.

  C. Treatment method: During construction, clean the attachments on the chassis in time.

Doosan Diagnostic Tool DDT G2 SCAN( ECU ,DCU)Software 2016

How to Dismantle Doosan Excavator Pump

How to dismantle Doosan  DX 60-9C excavator pump

 Disassembly of the plunger pumps and the gear pumps

1. Remove the bolts (M1025L: 2), because the decomposition plunger pump and gear pump have O-ring on the joint surface, please be careful when separating.

· Tool: 8mm (factory —)

Doosan Diagnostic Tool UVIM Support Doosan Excavators High Quality



 Figure  30

 2. Remove the coupling spline sleeve.



  Figure  31

 Disassemble the plunger pump

1. Remove the inner hexagon bolt (33,34) and separate the pump from the housing

End cover (21).

(M1230:3) (M1255:1)

· Tool: 10mm (factory —)



2. When removing the end cover, please separate in the horizontal direction. When the b is difficult to remove, please tap it gently with a plastic hammer.

 2020 Doosan Daewoo Excavator Operation and Repair Manual PDF



 3. Status after the pump end cover is removed.







4. Remove the O-ring (3 0,3 1).







5. Remove the adjustment spring.



    6. Remove the spring seat from the pump housing (51).





7. Remove the plunger plug assembly.







8. Use the hook to remove the slide track plate.





  2022.11 Doosan DMS-5 3.0.5 Data Monitoring System Diagnostic Software

9. Remove the clamp spring with the clamp (7).



   10. Remove the front cover (8).





       11. Remove the O-ring.





      14. Remove the bearing pads (14).





    15. Remove the bearing.







16. Remove the inclined plate.





    17. Remove the flow distribution plate.



 18. Remove the card spring (28).







19. Remove the filter screen (26).









20 Remove the retaining bolt (67) for the flow adjustment valve block (M8 x

25L: 2s)

If the bolt is coated with Loctite before assembly, please do not remove the cover bolt if not necessary.

· Tool: 6mm (factory 1)





   Doosan Diagnostic Tool DDT G2 SCAN( ECU ,DCU)Software 2016

21. Separate and adjust the valve body. Because the binding surface has an O-ring, please be careful.



 22. Remove the flow adjustment valve spool.





    23. Remove the 3 disc springs and spring seats.





24. Remove the inner hexagon bolts and separate the cover bolts

(M830L: 2s)

· Tool: 6mm (factory —)





  26. Remove the overflow valve. Remove the inner hexagon bolts.

Note: Disassemble this part only if required.

· Tool: 24 mm (2e)







27. Remove the adjustment bolts

 Note: Due to the valve core.





   28. Separation spring.







29. Remove the spool.

 30. Disassembly of the drive shaft

 Remove the clamp spring and the bearing







      31. It may be difficult to remove the bearings and can be struck with a plastic hammer.
